Skripsi

ANALISIS RUGI-RUGI DAYA DAN JATUH TEGANGAN PADA PENYULANG LAKITAN DI PT. PLN PERSERO GARDU INDUK KAMBANG UP3 PADANG

---

Penilaian

---

The activity of using electricity will continue to increase, this is related to the level of development and the increasing number of residents in an area or region. One of the efforts made in meeting these needs is to maintain the quality of the electricity distribution process so that it remains good. In the electricity distribution system, the amount of voltage and electrical power that is distributed is not the same as that received so that it will have an impact on economic losses during the distribution process. Therefore, a study was conducted to analyze the magnitude of the voltage drop and power losses that occurred in the Lakitan substation Kambang UP3 Padang feeder by using the manual calculation method and then comparing the values obtained with the standard limits that have been set. Based on the calculation results obtained from the Lakitan feeder with a length of 21,502 km, the power losses that occur are 17,249.9738 Watts or 17.25 kW and the voltage drop that occurs is 273.811 V with a percentage of 1.39%. The power losses and voltage drops are still within the standard limits set by PT. PLN (Persero) according to SPLN 1: 1995 concerning the standard limit for the voltage drop in the distribution system of 20 kV and with the smallest power loss values.

---

Availability

Inventory Code	Barcode	Call Number	Location	Status
2207004504	T81961	T819612022	Central Library (Referens)	Available

Detail Information

Series Title

-

Call Number

T819612022

Publisher

Indralaya : Prodi Teknik Elektro, Fakultas Teknik Universitas Sriwijaya ;., 2022

Collation

xv, 46 hlm.; ilus.; 29 cm

Language

Indonesia

ISBN/ISSN

-

Classification

621.139 07

Content Type

Text

Media Type

-

Carrier Type

-

Edition

-

Subject(s)

Transmisi dan distribusi listrik
Teknik elektro

Specific Detail Info

-

Statement of Responsibility

MURZ
